China 35cbm 50ton rear dump semi trailer

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Fudeng
  • Axle:Three Axles
  • Color:Custom's Requirement
  • Max Payload: 60 ton
  • We're here to help:
    Easy ways to get the answers you need.

    • China 35cbm 50ton rear dump semi trailer
    • China 35cbm 50ton rear dump semi trailer
    • China 35cbm 50ton rear dump semi trailer
    • China 35cbm 50ton rear dump semi trailer

    · Product Description


    China 35cbm 50ton rear dump semi trailer

    FUDENG produces Dump Tipping Semi trailers are ideal equipment to transport of sand Coal Stone Mental and other Construction material.We can supply 2 axles, 3 axles, 4 axles Dump tipping semi trailers which loading capacity from 40 ton ton 80 ton for customer specific requirements.FUDENG tipper trailer are equipped with HYVA cylinder, which is more reliable and more safety, all key parts of Daump tipping semi trailers are from famous brands both at home and aboard. Because of Reliability, durability and the low maintenance of Dump tipping trailer have been appreciated around the world.





    dump semi trailer drawing



    Click here to watch dump semi trailer video




    dump semi trailerSpecifications

    Tank Body

    Shape

    Rectangle or U shape

    Dimension

    7.5-12m×2.5×4m (Outside)

    Payload

    40T-100T

    Tare weight

    About 7.5T-15T

    Lifting system

    Full set of Hyva hydraulic system/Chinese brand

    Chassis

    Frame

    Welding design or Special design I beam, connected by bolts and nuts, Q345B carbon steel material

    Frame Beam

    Upper and lower plate is20mm,middle is10mm.height is 500 mm

    Frame Floor

    The Thickness is 3-8 mm flat bed

    Axle

    2 or 3 axles, BPW/FUWA/HUAJING brand

    Landing Gear

    JOST (D200T) or CHINA BRAND 28T

    King Pin

    JOST 2.00 or 3.5 inch bolt-in king pin

    Suspension

    Mechanical suspension/Germany or America type/air suspension

    Leaf Spring

    90mm(W)*13mm(T)*10 Layer/90mm(W)*16mm(T)*10 Layer/ 100mm(W)*16mm(T)*10 Layer

    Pneumatic Braking System

    WABCO RE 6 relay valve; Spring brake chamber (TKL brand); one piece of 45L air tanks.

    Rim

    8.5-20,9.0-20,8.25-22.5,9.0-22.5 optional

    Tire

    11.00R20,12.00R20,11R22.5,12R22.5,315/80R22.5 Tire optional

    ABS

    Optional

    Accessories

    One standard tool box

    Voltage

    24V

    Packing and shipping

    Painting

    Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint

    Shipping Terms

    By Bulk Cargo/RORO
